Description

REF615E-D-HBFDACADANB1BNN1XD-7700059450 ABB

Product Overview:

ABB REF615E-D-HBFDACADANB1BNN1XD-7700059450 is a 615A rated current circuit breaker with the following features:

Frame size:E

Rated voltage:400V

Rated frequency:50/60Hz

Breaking capacity:100kA

Trip type:electronic

Installation mode:fixed

Product parameters:

Parameter value

Model REF615E-D-HBFDACADANB1BNN1XD-7700059450

Rated current 615A

Rated voltage 400V

Rated frequency 50/60Hz

Breaking capacity 100kA

Trip type electronic

Installation mode fixed

Auxiliary contact 2NO+2NC

Terminal M8

Enclosure protection class IP20

Operating ambient temperature-25℃~+70℃

Meets standard IEC/EN 60947-2

Product Application:

REF615E-D-HBFDACADANB1BNN1XD-7700059450 circuit breakers are used in various low-voltage distribution systems as overload and short circuit protection for motors,transformers,cable lines,etc.

Brand Introduction:

ABB is the world’s leading electrical and automation technology group,committed to providing competitive solutions for the digital age.ABB’s products,services and solutions span the power,industrial,transportation and infrastructure sectors to help customers improve productivity,reduce energy consumption and improve environmental impact.
